Interfaces for level sensors, 4-20mA, Modbus RTU, Ethernet TCP, counter signal, relay.
Via the Wago hardware, the interfaces can be flexibly extended.
Password-protected for various use levels.
5 selectable mail recipients for fill level information.
Comes with English & German language as standard; other languages available on request.
For control and activation of pinch valves within filling tubes.
For integration of truck operating modules at filling station stage.
Level detection at external sites via internet.
For data storage and downloads, trend data and evaluation.
Fully wired within the control cabinet or on a t-rail module with electrical plans.
· Cabinet Material | · Sheet steel, IP54, 0°C to +55°C |
· Truck Operation Module Material | · Sheet steel, IP65, -20°C to +55°C |
· Supply Voltage | · 115V or 230V 50/60Hz |
· Number of Silos | · max. 128 depending on the configuration |
· Software | · License free software based on HTML. Password protected access via browser software |
· Hardware | · Wago, easily updatable |
· Input Signal | · NB3000 Modbus RTU, 4-20mA Analog input, Lot system counter pulse, Ethernet TCP |
· 'Silo Full' Alarm | · Horn and acknowledge button, IP66 for outdoor installation/mounting |
· Cabinet Display/View Door | · Optional touch panel 10.4" or 15" or LED display |
· Trend Data | · Internally programmed controller as ring memory, as exportable csv file or as required |
· Truck Module | · Optional: Silo mounted, silo display "full" with LED flashing warning and horn, acknowledgment via button |
· Shut Off Valve | · Optional: Filling release and overfill protection |
暫無數據！
在選煤廠生產過程中，原煤倉起著儲煤和均衡輸煤的用途。煤倉料位是保證選煤廠連續生產、設備安全以及產量計量的重要參數。依靠監測原煤倉的料位，可以對進入洗選的原煤量監測和控制，反饋給整個選煤流程控制系統，從
